Main Features:
The machine adopts a gear structure to reduce the speed, which is very durable.
The main part is a two-way piston pump. The structure is simple, compact and easy to maintain.
The machine has high pressure, large flow, good efficiency and very obvious protection effect.
The main spraying parts are three nozzles, which are self-developed and uniquely adopted by our factory in China, with a wide spraying range.
MODEL: | PS767A |
| Engine type : | TU26 |
| Engine : | Single cylinder, Two-stroke, Air-cooling |
| Displacement : | 26cc |
| Working speed : | 8000rpm |
| Idle speed : | 3000rpm |
| Power : | 0.75kW / 1.0HP |
| Chemist tank : | 20L |
| Fuel tank : | 1.0L |
| Suction volume : | 5-7 L/min |
| Pressure : | 15-25kg/cm² |
| Fuel mixture ratio : | 25:1(Gasoline 25 : 2-cycle Oil 1) |
| Package : | 420x350x640mm |
| N.W./G.W. : | 11.5kg/13.5kg |
| Qty.:20'/40'HQ : | 380pcs/780pcs |
If you are a importer, wholesaler or distributor of garden machinery, outdoor power Equipments, agricultural machinery, outboard motors, welcome to contact us for quotation.
We specialize in outdoor power equipment & parts (chainsaws, brushcutters, sprayers, generators, outboard motors, etc.) with over 10 years of expertise.
